1:3 Surface Mount Flyback Transformer, 6.78μH, 0.02Ω

Description

Primary DC Resistance: 0.02Ω

Isolation Voltage: 2.5kV

Dimensions: 25 x 22.2 x 16mm

Mounting Type: Surface Mount

Secondary Voltage Rating: 5 V, 15 V

Leakage Inductance: 200nH

Minimum Temperature: -40°C

Length: 25mm

Width: 22.2mm

Depth: 16mm

Maximum Temperature: +125°C

Turns Ratio: 1:3

Primary Voltage Rating: 8V Primary Inductance: 6.78µH Power Rating: 12W Secondary DC Resistance: 0.45 (12-11 and 10-9) Ω, 0.47 (14-13 and 8-7) Ω

This is 1:3 Surface Mount Flyback Transformer 6.78μH 0.02Ω manufactured by Wurth Elektronik. The manufacturer part number is 750311911. Additionally, it has 0.02ω primary DC resistance . It has 2.5kv isolation voltage. The given dimensions of the product include 25 x 22.2 x 16mm. The product is available in surface mount configuration. In addition, it has a secondary 5 v, 15 v voltage rating . It has about 200nh leakage inductance . While its minimum temperature is -40°c. Its accurate length is 25mm. Furthermore, the product is 22.2mm wide. The product comes in 16mm depth. The product has +125°c maximum temperature. It has 1:3 turns ratio . It has about 8v primary voltage rating . Additionally, it has 6.78µh primary inductance . Feature 12w of power rating. It has about 0.45 (12-11 and 10-9) ω, 0.47 (14-13 and 8-7) ω secondary DC resistance .
