Analog Devices ADF4360-9BCPZ, Frequency Synthesizer, 24-Pin CP 24 2

Description

Dimensions: 4 x 4 x 0.83mm

Mounting Type: Surface Mount

Maximum Output Frequency: 400MHz

Minimum Output Frequency: 1.1MHz

Minimum Operating Supply Voltage: 3 V

Maximum Supply Current: 5 mA

Height: 0.83mm

Width: 4mm

Length: 4mm

Maximum Input Frequency: 250MHz

Package Type: CP 24 2

Number of Elements per Chip: 1

Minimum Operating Temperature: -40 °C Maximum Operating Supply Voltage: 3.6 V Maximum Operating Temperature: +85 °C Pin Count: 24

This is Frequency Synthesizer 24-Pin CP 24 2 manufactured by Analog Devices. The manufacturer part number is ADF4360-9BCPZ. The given dimensions of the product include 4 x 4 x 0.83mm. The product is available in surface mount configuration. Additionally, it has a maximum 400mhz output frequency . It has a minimum 1.1mhz output frequency . While its minimum operating supply voltage is 3 v. Moreover, it has a maximum 5 ma supply current . In addition, the height is 0.83mm. Furthermore, the product is 4mm wide. Its accurate length is 4mm. The product has a maximum 250mhz input frequency . The package is a sort of cp 24 2. It consists of 1 elements per chip. Whereas, the minimum operating temperature of the product is -40 °c. It has 3.6 v maximum operating supply voltage. It has a maximum operating temperature of +85 °c. It contains 24 pins.
