Bourns SA Series 6300V 5kA Axial 2 Electrode Gas Discharge Tube

Description

Dimensions: 8.5 (Dia.) x 8.9mm

Mounting Type: Axial

Series: SA

Minimum Operating Temperature: -40°C

DC Spark Over Voltage: 6300V

Length: 8.9mm

Maximum Voltage Rating: 6300 V

Impulse Spark Over Voltage: 9200V

Maximum Surge Current: 5kA

Maximum Operating Temperature: +125°C

Suppressor Type: 2 Electrode Gas Discharge Tube

This is SA Series 6300V 5kA Axial 2 Electrode Gas Discharge Tube manufactured by Bourns. The manufacturer part number is SA2-6300-CLT-STD. The given dimensions of the product include 8.5 (dia.) x 8.9mm. The product is available in axial configuration. The product sa, is a highly preferred choice for users. Whereas, the minimum operating temperature of the product is -40°c. Additionally, the product has 6300v DC spark over voltage . Its accurate length is 8.9mm. It has a maximum 6300 v voltage rating. It has 9200v impulse spark over voltage . It can withstand a maximum 5ka surge current . It has a maximum operating temperature of +125°c. Its suppressor is of 2 electrode gas discharge tube type .
