DIN Rail Power Supply, 31.2W, 24V dc/ 1.3A

Description

Maximum Temperature: +70°C

AC or DC Output Voltage: dc

Dimensions: 36 x 53 x 90mm

Minimum Temperature: -25°C

AC or DC Input Voltage: ac

Width: 36mm

MTBF: 3094996h

Electrical Phase: 1

Type: Switched Mode

Load Regulation: 0.1%

Standards Met: CB, CE Marked, CSA C22.2 No. 107.1, CSA C22.2 No. 60950, cULus, cURus Recognised, File E151273, File E197259, FM Approval, NEC Class 2, UL 508, UL 60950

Efficiency: 86%

Input Voltage: 100 → 240V ac Number of Outputs: 1 Output Voltage Adjustment Range: 22.2 → 26.4V Ripple And Noise: 200mV Pk-Pk Depth: 53mm Special Features: Flexible Deployment, Flexible Mounting, Global Use, High Energy Efficiency, Load Monitoring, Low Width, Reliable, Wide Portfolio Mounting Type: DIN Rail Mount Output Current: 1.3A Series: LOGO POWER Height: 90mm Output Voltage: 24V dc Power Rating: 31W

This is DIN Rail Power Supply 31.2W 24V dc/ 1.3A manufactured by Siemens. The manufacturer part number is 6EP3331-6SB00-0AY0. The product has +70°c maximum temperature. It has a/an dc output voltage . The given dimensions of the product include 36 x 53 x 90mm. While its minimum temperature is -25°c. It has ac input voltage. Furthermore, the product is 36mm wide. The MTBF values include 3094996h. Its electrical phase configuration includes 1. It comes in switched mode configuration. Load Regulation – 0.1%. The product complies with all safety standards, such as cb, ce marked, csa c22.2 no. 107.1, csa c22.2 no. 60950, culus, curus recognised, file e151273, file e197259, fm approval, nec class 2, ul 508, ul 60950. It is a highly efficient product with an 86% of high efficiency. Its input voltage is 100 → 240v ac. Additionally, the product is supplied with 1 outputs. It has 22.2 → 26.4v of output voltage adjustment range. Carries 200mv pk-pk ripple and noise. The product comes in 53mm depth. The product also provides special features, such as flexible deployment, flexible mounting, global use, high energy efficiency, load monitoring, low width, reliable, wide portfolio. The product is available in din rail mount configuration. It carries 1.3a output current. The product logo power, is a highly preferred choice for users. In addition, the height is 90mm. Features a 24v dc output voltage. Feature 31w of power rating.
