Finder SPDT Latching Relay DIN Rail, 240V ac Coil, 12 A Call and Reset

Description

Life: 100000 (Electrical) cycles

Maximum Operating Temperature: +60°C

Mounting Type: DIN Rail

Coil Power: 700mW

Series: 13 Series

Latching: Yes

Coil Voltage: 230V ac

Depth: 60.8mm

Height: 88.8mm

Switching Current: 12A

Application: General Purpose

Length: 17.5mm

Maximum Switching Voltage AC: 400V ac Minimum Operating Temperature: -10°C Maximum Switching Power AC: 3 kVA Isolation Coil To Contact: 2kV Contact Configuration: SPDT Number of Poles: 1 Terminal Type: Screw Contact Material: Silver Alloy

This is SPDT Latching Relay DIN Rail 240V ac Coil 12 A Call and Reset manufactured by Finder. The manufacturer part number is 13.11.8.230.0000. It is capable of doing 100000 (electrical) cycles in a lifetime . It has a maximum operating temperature of +60°c. The product is available in din rail configuration. Robust coil power of 700mw. The product 13 series, is a highly preferred choice for users. Latching Options – yes. The coil voltage of the product is 230v ac. The product comes in 60.8mm depth. In addition, the height is 88.8mm. It is integrated with 12a switching current. Applications Information involves general purpose. Its accurate length is 17.5mm. It has a maximum AC switching voltage of 400v ac. Whereas, the minimum operating temperature of the product is -10°c. It also features an AC switching power of 3 kva. The product has 2kv isolation coil to contact. The contact is equipped with spdt configuration. It has equipped with 1 poles. The terminal is a screw type. The product is made from sturdy silver alloy materials.
