MTL Crouse-Hinds, Converter Signal Conditioner,

Description

Output Signal Type: Current, Voltage

Mounting Type: DIN Rail Mount

Operating Temperature Range: -20 → +60°C

Output Range: 0 → 10 V, 0 → 20 mA, 0 → 5 V, 1 → 5 V, 2 → 10 V, 4 → 20mA

Series: MTL

Module Type: Analogue Signal Converter

Input Range: 0 → 1 V, 0 → 10 V, 0 → 100 mV, 0 → 2 mA, 0 → 5 V, 1 → 5 V, 4 → 20mA

Input Signal Type: Current, Voltage

Supply Voltage: 18 → 32V dc

Minimum Operating Temperature: -20°C

Termination: Screw

Maximum Operating Temperature: +60°C

This is Crouse-Hinds Converter Signal Conditioner manufactured by MTL. The manufacturer part number is MTL1249. The output signal is a kind of current, voltage. The product is available in din rail mount configuration. The product has -20 → +60°c of operating temperature range. Has a 0 → 10 v, 0 → 20 ma, 0 → 5 v, 1 → 5 v, 2 → 10 v, 4 → 20ma of output range. The product mtl, is a highly preferred choice for users. It has a/an analogue signal converter type module . Typical input range of 0 → 1 v, 0 → 10 v, 0 → 100 mv, 0 → 2 ma, 0 → 5 v, 1 → 5 v, 4 → 20ma. The input signal is a kind of current, voltage signal. Features 18 → 32v dc supply voltage. Whereas, the minimum operating temperature of the product is -20°c. The product features screw termination style. It has a maximum operating temperature of +60°c.
