Pepperl + Fuchs, M18 x 1, NO Inductive Sensor 40mm Length, 5 → 60 V dc supply voltage , IP67 Rating

Description

Output Function: NO

Switching Frequency: 350 Hz

Housing Material: Stainless Steel

Supply Voltage: 5 → 60 V dc

Shielding: Shielded

Maximum Switching Frequency: 350Hz

Reverse Polarity Protection: Yes

Detection Range: 5 mm

Body Style: Threaded Barrel

Maximum Operating Temperature: +70°C

IP Rating: IP67

Switching Current: 100 mA

Digital Switching Output Type: 2-Wire Length: 40mm Maximum DC Voltage: 60V Thread Size: M18 Short Circuit Overload Protection: Yes Mounting Type: Flush Sensor Technology: Inductive Minimum Operating Temperature: -25°C Cable Length: 2m Connection Type: Pre-Cabled

This is M18 x 1 NO Inductive Sensor 40mm Length 5 → 60 V dc supply voltage IP67 Rating manufactured by Pepperl + Fuchs. The manufacturer part number is NCB5-18GM40-Z0. The no is the output function of the product. It exhibits a typical 350 hz switching frequency . The product also features robust stainless steel housing material. Features 5 → 60 v dc supply voltage. Furthermore, the product is shielded with shielded. It has a maximum 350hz switching frequency. Reverse Polarity Protection Options – yes. The product has 5 mm of detection range. It has a threaded barrel body style. It has a maximum operating temperature of +70°c. It is IP rated with ip67. It is integrated with 100 ma switching current. Its accurate length is 40mm. It has 60v maximum DC voltage. It has a typical thread size of m18. Short Circuit Overload Protection Options – yes. The product is available in flush configuration. The sensor utilises inductive, a standard technology in sensor markets. Whereas, the minimum operating temperature of the product is -25°c. Furthermore, the cable has a 2m of length. It allows pre-cabled connection type.
