Pepperl + Fuchs SC-System, Temperature Converter Signal Conditioner, Analogue

Description

Output Signal Type: Current, Voltage

Mounting Type: DIN Rail Mount

Operating Temperature Range: -25 → +70°C

Output Range: 0 → 10 mA, 0 → 10 V, 0 → 20 mA, 0 → 5 V, 1 → 5 V, 2 → 10 mA, 2 → 10 V, 4 → 20mA

Series: S1SD

Module Type: Temperature Converter

Input Range: (Resistor) 0 → 5 kΩ, (Potentiometer) 0.2 → 50 kΩ, (PTC) -100 → +100 mV, -1000 → +1000 mV, (RTD) 200µA

Input Signal Type: RTD, Potentiometer, Thermocouple, Voltage

Supply Voltage: 16.8 → 31.2V dc

Minimum Operating Temperature: -25°C

Termination: Screw

Maximum Operating Temperature: +70°C

This is SC-System Temperature Converter Signal Conditioner Analogue manufactured by Pepperl + Fuchs. The manufacturer part number is S1SD-1TI-1U. The output signal is a kind of current, voltage. The product is available in din rail mount configuration. The product has -25 → +70°c of operating temperature range. Has a 0 → 10 ma, 0 → 10 v, 0 → 20 ma, 0 → 5 v, 1 → 5 v, 2 → 10 ma, 2 → 10 v, 4 → 20ma of output range. The product s1sd, is a highly preferred choice for users. It has a/an temperature converter type module . Typical input range of (resistor) 0 → 5 kω, (potentiometer) 0.2 → 50 kω, (ptc) -100 → +100 mv, -1000 → +1000 mv, (rtd) 200µa. The input signal is a kind of rtd, potentiometer, thermocouple, voltage signal. Features 16.8 → 31.2v dc supply voltage. Whereas, the minimum operating temperature of the product is -25°c. The product features screw termination style. It has a maximum operating temperature of +70°c.
