Description
Maximum Clamping Voltage: 520V
Maximum Peak Pulse Current: 1kA
Maximum Reverse Stand-off Voltage: 380V
Dimensions: 14.5 x 8 x 8mm
Mounting Type: Through Hole
Capacitance: 120pF
Minimum Breakdown Voltage: 401V
Direction Type: Bi-Directional
Height: 8mm
Width: 8mm
Length: 14.5mm
Number of Elements per Chip: 1
Minimum Operating Temperature: -55 °C Working Voltage: 380V Maximum Operating Temperature: +125 °C Pin Count: 2 Test Current: 10mA
This is PTVS VWM 380V 1kA BIDIR manufactured by Bourns. The manufacturer part number is PTVS1-380C-TH. It is supplied with 520v of maximum clamping voltage. It also has 1ka maximum peak pulse current. While the maximised reverse stand-off voltage includes 380v. The given dimensions of the product include 14.5 x 8 x 8mm. The product is available in through hole configuration. It provides a 120pf of capacitance value. It harbours a 401v of minimum breakdown voltage. While is configured as bi-directional. In addition, the height is 8mm. Furthermore, the product is 8mm wide. Its accurate length is 14.5mm. It consists of 1 elements per chip. Whereas, the minimum operating temperature of the product is -55 °c. It has about [Working Voltage] working voltage . It has a maximum operating temperature of +125 °c. It contains 2 pins. In addition, it has 10ma test current.
