Schneider Electric 2 A SPNO Solid State Relay, AC Switching, PCB Mount SCR, 280 V ac Maximum Load

Description

Dimensions: 28 x 5 x 15mm

Relay Type: Single Phase

Capacitance: 1.5pF

Maximum Load Voltage: 280 V ac

Output Device: SCR

Load Voltage Range: 24 → 280V ac

Standards Met: CE, CSA, UL

Minimum Control Voltage: 3 V dc

Off State Leakage Current: 4 mA

Switching Type: AC

Terminal Type: PCB Pin

Control Voltage Range: 3 → 12 V dc

Operating Temperature Range: -20 → +80°C Minimum Load Current: 0.07 A Contact Configuration: SPST Length: 28mm Maximum Turn On Time: 1/2 cycle Special Features: Built-In Diode Protection Circuit & LED Indicator, Mounted on Universal AC/DC Sockets, Slim Interface SSL Relays with PCB Terminals Maximum Load Current: 2 A Better World Verification: Green Premium Better World Product: Yes Mounting Type: PCB Mount Series: Harmony Relay Depth: 5mm Height: 15mm Maximum Control Voltage: 12 V dc Number of Poles: 1 Minimum Load Voltage: 24 V ac

This is 2 A SPNO Solid State Relay AC Switching PCB Mount SCR 280 V ac Maximum Load manufactured by Schneider Electric. The manufacturer part number is SSL1A12JD. The given dimensions of the product include 28 x 5 x 15mm. This is basically a single phase. It provides a 1.5pf of capacitance value. While its maximum load voltage is 280 v ac. Its output device includes scr. Its load voltage range is about 24 → 280v ac . The product complies with all safety standards, such as ce, csa, ul. Additionally, it has a minimum 3 v dc control voltage . Additionally, its off state leakage current is 4 ma . This product uses ac switching mechanism. The terminal is a pcb pin type. Moreover, it has a typical 3 → 12 v dc control voltage range . The product has -20 → +80°c of operating temperature range. The product has a minimum 0.07 a load current . The contact is equipped with spst configuration. Its accurate length is 28mm. The product has a maximum 1/2 cycle turn on time . The product also provides special features, such as built-in diode protection circuit & led indicator, mounted on universal ac/dc sockets, slim interface ssl relays with pcb terminals. It carries 2 a maximum load current. Better World Verification Options – green premium. Is it a better world product? yes. The product is available in pcb mount configuration. The product harmony relay, is a highly preferred choice for users. The product comes in 5mm depth. In addition, the height is 15mm. The product has a maximum 12 v dc control voltage . It has equipped with 1 poles. It carries up to 24 v ac minimum load voltage.
