TT Electronics/BI 67WR1KLF

Description

Shaft Diameter: 2.29 (Metal Adjustment Screw) mm

Orientation: Top Adjust

Mounting Type: Through Hole

Series: 67

Minimum Operating Temperature: -55°C

Termination Style: Solder Pin

Number of Turns: 20

Temperature Coefficient: ±100ppm/°C

Length: 9.53mm

Maximum Resistance: 1kΩ

Maximum Voltage Rating: 200 V dc

Power Rating: 0.5W

Element Material: Cermet Tolerance: ±10% Maximum Operating Temperature: +125°C HTSUS: 8533.40.8050 RoHS Status: ROHS3 Compliant Termination Style: PC Pins Temperature Coefficient: ±100ppm/°C Number of Turns: 20 Power (Watts): 0.5W, 1/2W Adjustment Type: Top Adjustment Tolerance: ±10% REACH Status: REACH Unaffected edacadModel: 67WR1KLF Models Resistive Material: Cermet edacadModelUrl: /en/models/2408667Package: Bulk Size / Dimension: Rectangular – 0.375″ x 0.195″ Face (9.53mm x 4.95mm) standardLeadTime: 17 Weeks Moisture Sensitivity Level (MSL): Not Applicable Mounting Type: Through Hole Series: 67 Resistance: 1 kOhmsBase Product Number: 67WR ECCN: EAR99

This ismanufactured by TT Electronics/BI. The manufacturer part number is 67WR1KLF. The diameter of the shaft is 2.29 (metal adjustment screw) mm. The product has a top adjust orientation. The product is available in through hole configuration. The product 67, is a highly preferred choice for users. Whereas, the minimum operating temperature of the product is -55°c. Moreover, it has solder pin terminal style. Consist of 20 turns. It exhibits an excellent temperature coefficient of ±100ppm/°c. Its accurate length is 9.53mm. The product offers a maximum resistance up to 1kω. It has a maximum 200 v dc voltage rating. Feature 0.5w of power rating. Moreover, its element is of cermet material . It features ±10% of tolerance value. It has a maximum operating temperature of +125°c. It is assigned with possible HTSUS value of 8533.40.8050. The product is rohs3 compliant. Moreover, it has pc pins terminal style. The product features power and watts of 0.5w, 1/2w. It has adjustment flexibility and is adjusted at a top adjustment. In addition, it is reach unaffected. The product is equipped with a cermet resistive material. It is shipped in bulk package . The product’s diameters include rectangular – 0.375″ x 0.195″ face (9.53mm x 4.95mm). It has a long 17 weeks standard lead time. Its typical moisture sensitivity level is not applicable. It carries 1 kohms resistance. Moreover, it corresponds to 67wr, a base product number of the product. The product is designated with the ear99 code number.
