2.33:1 Surface Mount Flyback Transformer, 15μH, 0.035Ω

Description

Primary DC Resistance: 0.035Ω

Isolation Voltage: 2.5kV

Dimensions: 32.31 x 27.03 x 13.69mm

Mounting Type: Surface Mount

Secondary Voltage Rating: 10 V, 12 V

Leakage Inductance: 550nH

Minimum Temperature: -40°C

Length: 32.31mm

Width: 27.03mm

Depth: 13.69mm

Maximum Temperature: +85°C

Turns Ratio: 2.33:1

Primary Voltage Rating: 30 → 75V Primary Inductance: 15µH Power Rating: 45W Secondary DC Resistance: 0.015Ω

This is 2.33:1 Surface Mount Flyback Transformer 15μH 0.035Ω manufactured by Wurth Elektronik. The manufacturer part number is 750311594. Additionally, it has 0.035ω primary DC resistance . It has 2.5kv isolation voltage. The given dimensions of the product include 32.31 x 27.03 x 13.69mm. The product is available in surface mount configuration. In addition, it has a secondary 10 v, 12 v voltage rating . It has about 550nh leakage inductance . While its minimum temperature is -40°c. Its accurate length is 32.31mm. Furthermore, the product is 27.03mm wide. The product comes in 13.69mm depth. The product has +85°c maximum temperature. It has 2.33:1 turns ratio . It has about 30 → 75v primary voltage rating . Additionally, it has 15µh primary inductance . Feature 45w of power rating. It has about 0.015ω secondary DC resistance .
