ON Semiconductor FFSH50120A

Description

Mounting Type: Through Hole

Maximum Continuous Forward Current: 77A

Peak Non-Repetitive Forward Surge Current: 1.7kA

Diode Technology: Schottky

Package Type: TO-247

Number of Elements per Chip: 1

Diode Type: SiC Schottky

Diode Configuration: Single

Pin Count: 2

Peak Reverse Repetitive Voltage: 1200V

Manufacturer Standard Lead Time: 48 Weeks

Base Part Number: FFSH50120

Detailed Description: Diode Silicon Carbide Schottky 1200V 77A (DC) Through Hole TO-247-2 Reverse Recovery Time (trr): 0ns Current – Reverse Leakage @ Vr: 200µA @ 1200V Operating Temperature – Junction: -55°C ~ 175°C Mounting Type: Through Hole Voltage – DC Reverse (Vr) (Max): 1200V Capacitance @ Vr, F: 2560pF @ 1V, 100kHz Supplier Device Package: TO-247-2 Packaging: Tube Customer Reference: Current – Average Rectified (Io): 77A (DC) Package / Case: TO-247-2 Diode Type: Silicon Carbide Schottky Speed: No Recovery Time > 500mA (Io) Manufacturer: ON Semiconductor

This ismanufactured by ON Semiconductor. The manufacturer part number is FFSH50120A. The product is available in through hole configuration. Furthermore, its maximum continuous forward current constitutes 77a. Moreover, a bespoke product has 1.7ka peak non-repetitive forward surge current. The product utilizes schottky diode technology. The package is a sort of to-247. It consists of 1 elements per chip. It is designed with a sic schottky diode. The diode features a single configuration. It contains 2 pins. While having the peak reverse repetitive 1200v. It has typical 48 weeks of manufacturer standard lead time. Base Part Number: ffsh50120. It features diode silicon carbide schottky 1200v 77a (dc) through hole to-247-2. It has a trr (reverse recovery time) of 0ns. 200µa @ 1200v is the reverse leakage value of a bespoke product. The product operate at temperatures ranging from -55°c ~ 175°c. While it has maximum reverse voltage of 1200v. Moreover, the product has a 2560pf @ 1v, 100khz capacitance. to-247-2 is the supplier device package value. In addition, tube is the available packaging type of the product. It features a 77a (dc) of average rectified current. Moreover, the product comes in to-247-2. It is designed with a silicon carbide schottky diode. It has a robust speed of no recovery time > 500ma (io). The on semiconductor’s product offers user-desired applications.
