ON Semiconductor HCPL0600R2

Description

Maximum Forward Voltage: 1.8V

Output Device: Logic Gate

Isolation Voltage: 3.75 kVrms

Mounting Type: Surface Mount

Typical Rise Time: 50ns

Input Current Type: DC

Number of Pins: 8

Number of Channels: 1

Package Type: SOIC

Maximum Input Current: 15 mA

Logic Output: Yes

Typical Fall Time: 12ns

Manufacturer Standard Lead Time: 18 Weeks Detailed Description: Logic Output Optoisolator 10Mbps Open Collector 3750Vrms 1 Channel 5kV/µs CMTI 8-SOIC Propagation Delay tpLH / tpHL (Max): 75ns, 75ns Operating Temperature: -40°C ~ 85°C Input Type: DC Package / Case: 8-SOIC (0.154″, 3.90mm Width) Base Part Number: HCPL0600 Rise / Fall Time (Typ): 50ns, 12ns Output Type: Open Collector Current – DC Forward (If) (Max): 50mA Number of Channels: 1 Data Rate: 10Mbps Manufacturer: ON Semiconductor Current – Output / Channel: 50mA Inputs – Side 1/Side 2: 1/0 Common Mode Transient Immunity (Min): 5kV/µs Voltage – Forward (Vf) (Typ): 1.75V (Max) Voltage – Isolation: 3750Vrms Mounting Type: Surface Mount Supplier Device Package: 8-SOIC Packaging: Cut Tape (CT) Voltage – Supply: 4.5V ~ 5.5V Customer Reference:

This ismanufactured by ON Semiconductor. The manufacturer part number is HCPL0600R2. It also carries 1.8v of maximum forward voltage. Its output device includes logic gate. It has 3.75 kvrms isolation voltage. The product is available in surface mount configuration. It has a typical 50ns rise time . Its input is of dc type . It is comprised of 8 pins. It is supplied with 1 channels. The package is a sort of soic. While its maximum input current includes 15 ma. It includes a logic output yes . It has a typical 12ns fall time . It has typical 18 weeks of manufacturer standard lead time. It features logic output optoisolator 10mbps open collector 3750vrms 1 channel 5kv/µs cmti 8-soic. It has a maximum propagation delay of 75ns, 75ns. The product has -40°c ~ 85°c operating temperature range. It carries dc input type. Moreover, the product comes in 8-soic (0.154″, 3.90mm width). Base Part Number: hcpl0600. The typical rise and fall time of the product is 50ns, 12ns. Furthermore, it has aopen collector output. The maximum DC forward current of the product is 50ma. It has a maximised data speed rate of 10mbps. The on semiconductor’s product offers user-desired applications. It carries 50ma output or channel current. The typical 1/0 inputs of both sides (side 1/side 2). Allows a 5kv/µs of minimum common mode transient immunity. The typical forward voltage (Vf) of the product is 1.75v (max). 3750vrms of isolation voltage. 8-soic is the supplier device package value. In addition, cut tape (ct) is the available packaging type of the product. It has optimum voltage supply of 4.5v ~ 5.5v.
